ONV Easy Managed Technical Snapshot: full-series store-and-forward, non-blocking wire speed; H53 series 12–54Gbps, 8.93–40.18Mpps; H51 series 12Gbps. PoE total power in four tiers—65W/120W/180W/250W, 30W per port, pins 1/2(+) 3/6(-). Uplink 2× Gigabit RJ45 + 1× SFP, supporting multimode 550m/single-mode 40km/120km. Management includes VLAN, port isolation, storm control, RSTP (<50ms), QoS, IGMP/DHCP Snooping.

ONV Distributor Selection Table: 4 ports—H53054/H53064 (65W); 8 ports—H53108 (Gigabit, 120W) or H51108 (100M, 120W); 16 ports—H53016 (250W) or H51016 (180W); 24 ports—H53024 (Gigabit, 250W) or H51024 (100M, 250W). Flagship best-sellers H53108/H53024; volume models H51108/H51024. All support cloud + APP remote PoE management; SFP modules bundle well.

ONV Easy Managed PoE Switch Series: 4/8/16/24 PoE ports. Full Gigabit H53 series (12–54Gbps, 65–250W) and 100M-access H51 series with Gigabit uplinks (120–250W). All models feature built-in power, IEEE 802.3af/at, 30W per port, Web/ONV-NMS cloud/mobile APP remote PoE management, VLAN, 4KV lightning protection, IP30, -20°C~+55°C, desktop/wall-mount. 1-year warranty, lifetime maintenance.

PoE extender is a connecting device on the physical layer of the network. It is suitable for the interconnection of two types of networks that are exactly the same. It expands the distance of network transmission by resending or forwarding data signals.

AI PoE switch Functions: 250-meter transmission, port VLAN isolation, power supply priority, and PoE watchdog.
